产品详情
HF60PP070D01大通量滤芯
HF60PP070D01大通量滤芯具有高精度、高效率、高流量、深层过滤和使用周期长等特点，它融合了聚丙烯(PP)熔喷、纤维多重复合以及专利打摺等先进技术，使单支滤芯较高流量可以达到110t/h，滤芯在1~70μm 范围内绝对过滤精度达到99.9%。大通量滤芯滤芯采用“O”型圈密封和独特的导流管设计，可以保证过滤效率，杜绝旁漏。HF60PP070D01大通量滤芯 相关型号
HF40PP001A01, HF40PP001B01, HF40PP001C01, HF40PP001D01, HF40PP002A01, HF40PP002B01, HF40PP002C01,
HF40PP002D01, HF40PP005A01, HF40PP005B01, HF40PP005C01, HF40PP005D01, HF40PP010A01, HF40PP010B01,
HF40PP010C01, HF40PP010D01, HF40PP015A01, HF40PP015B01, HF40PP015C01, HF40PP015D01, HF40PP025A01,
HF40PP025B01, HF40PP025C01, HF40PP025D01, HF40PP040A01, HF40PP040B01, HF40PP040C01, HF40PP040D01,
HF40PP070A01, HF40PP070B01, HF40PP070C01, HF40PP070D01, HF60PP001A01, HF60PP001B01, HF60PP001C01,
HF60PP001D01, HF60PP002A01, HF60PP002B01, HF60PP002C01, HF60PP002D01, HF60PP005A01, HF60PP005B01,
HF60PP005C01, HF60PP005D01, HF60PP010A01, HF60PP010B01, HF60PP010C01, HF60PP010D01, HF60PP015A01,
HF60PP015B01, HF60PP015C01, HF60PP015D01, HF60PP025A01, HF60PP025B01, HF60PP025C01, HF60PP025D01,
HF60PP040A01, HF60PP040B01, HF60PP040C01, HF60PP040D01, HF60PP070A01, HF60PP070B01, HF60PP070C01,
技术参数
HF60PP070D01大通量滤芯参数
规范内容 | 20英寸 | 40英寸 | 60英寸 |
滤元外形 | Φ152×508 | Φ152*1016 | Φ152×1535 |
滤元材质 | 滤材：PP；端盖：PP；衬网：PP | ||
过滤精度 | 1μm、4μm、5μm、10μm、20μm、50μm、100μm | ||
滤元形式 | 折叠式 | ||
最 高使用温度 | 80℃ | ||
最 大流量 | 20 m3/h | 40m3/h | 60 m3/h |
工作压差 | ≤0.245MPa | ||
过滤方式 | 内进外出 | ||
应用领域
HF60PP070D01大通量滤芯
1) RO保安过滤，海水淡化预处理
2) 电厂冷凝水的过滤
3） 生物制药行业原料药，溶剂，水的过滤
4) 瓶装水，糖液，食用油，果汁，软饮料，牛奶的过滤
5) 油漆，涂料，石油化工
6) 微电子，胶片，纤维，树脂
